Hyundai Elantra: Steering wheel / Heated Steering wheel Description and Operation

Hyundai Elantra AD (2016-2020) Service Manual / Steering System / Steering wheel / Heated Steering wheel Description and Operation

Description
For the convenience of drivers during the winter, exothermic paint is applied to the surface of the steering wheel to generate heat when it is gripped.
Heated control unit (Body control module(BCM))

Heated pad

Heated Steering wheel Components and Components Location
Components location (1) Heated steering wheel switch 1. Heated steering switch Components location (2) Heated steering wheel control module (Body control moduel(BCM)) 1. Body contorl ...

Heated Steering wheel Specifications
Specifications ItemSpecificationVoltage13.5 VHeated pad resistance1.7 ~ 0.2 ?  ± 0.2 ? NTC resistance10.0 k?  ± 10% (25°C) ...
